Criditpid Replacement 80456 Auger Motor for US Stove American Harvest 6039, 6041 Pellet Stove, 4 RPM Clockwise Auger Agitator Motor for USSC.
Product details
| Management number | 226132182 | Release Date | 2026/05/09 | List Price | US$16.80 | Model Number | 226132182 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This 4 RPM auger feed motor has a clockwise rotation (CW) as viewed from the shaft side. Not all stoves use the same connection type, if your unit needs different female/male spade clips, these can be removed and changed out.Specifications:★ Volts: 120V★ Amps: 0.72 A★ Cycles: 60 Hz★ RPM: 4.0★ Direction: Clockwise★ Wire Length: 20" with ¼" Male and Female TerminalReplacement for Part Number: 80456Compatibility:➤ US Stove Pellet Stoves:◆ American Harvest 6033 (Auger)◆ American Harvest 6035 (Auger)◆ American Harvest 6037 (Auger)◆ American Harvest 6039 (Auger)◆ American Harvest 6039HF (Auger)◆ American Harvest 6039i (Auger)◆ American Harvest 6039T (Auger)◆ American Harvest 6041 (Agitator)◆ American Harvest 6041HF (Agitator)◆ American Harvest 6041i (Agitator)◆ American Harvest 6041TP (Agitator)➤ Ashley/King Pellet Stoves:◆ APC1406 (Agitator)◆ APCi1406 (Agitator)Advantage & Benefit:👉 High Quality Motor👉 Powerful, Quiet, Energy Efficient and Long Lasting.
- Compatibility --- ➤ Replacement 80456 Auger / Agitator motor for US Stove American Harvest 6033, 6035, 6037, 6039, 6039HF, 6039i, 6039T, 6041, 6041HF, 6041i, 6041TP Pellet Stove. ➤ Replacement 80456 Agitator motor for Ashley King APC1406, APCi1406 Pellet Stove.
- The 80456 Auger/Agitator Motor Technical Specifications --- ★ Volts: 120V AC, ★ Amps: 0.72 A, ★ Cycles: 60 Hz, ★ RPM: 4.0, ★ Direction: Clockwise. ★ Wire Length: 20" with ¼" Male and Female Terminal. ➤ CW4H Auger/Agitator Motor.
- Replacement For Part Number: USSC 80456. ➤ High Quality Auger Motor: Powerful, Quiet, Energy Efficient and Long Lasting. 1 year warran/ty.
- High-quality & Easy to install --- ☞The 4RPM auger / agitator motor is easy to install with 20 inch wire, we provide both male and female spade connectors, depending on your stoves configuration. ☞The CW4 auger motor is made of quality stainless steel, durable material that can be applied for a long time
- Note: To best determine compatibility, please double check the spacing on your auger shaft. The auger shaft coils will be spaced 1" apart to indicate set up for 4RPM, whereas 2" spacing indicates set up for 1RPM.
| ASIN | B0CCLBJXJ3 |
|---|---|
| Speed | 4 RPM |
| Voltage | 110 Volts |
| Brand Name | Criditpid |
| Horsepower | 0.14 Horsepower |
| Item Weight | 1.58 Kilograms |
| Part Number | PSBA80456-CW4H |
| Material Type | Stainless Steel |
